SMC has a complete line of rectangular waveguide Low Power Precision Terminations. A unique custom load element is used to guarantee the most optimum electrical performance. VSWR is generally 1.02:1 or better over most full operating bandwidths.
Data Sheets (click to download):
Rectangular Low Power Termination
| Model Number | Waveguide Size | Frequency | VSWR | Dimension (L) inch |
|---|---|---|---|---|
| SMC-150010 | WR-10 | 75.0-110.0 GHz | Upon Request | 4 |
| SMC-150012 | WR-12 | 60.0-90.0 GHz | Upon Request | 4 |
| SMC-150015 | WR-15 | 50.0-75.0 GHz | Upon Request | 4 |
| SMC-150019 | WR-19 | 40 – 60 GHz | 1.05:1 | 4 |
| SMC-150022 | WR-22 | 33 – 50 GHz | 1.05:1 | 4 |
| SMC-150028 | WR-28 | 26.5 – 40 GHz | 1.05:1 | 6 |
| SMC-150034 | WR-34 | 22-33 GHz | 1.05:1 | 6 |
| SMC-150042 | WR-42 | 18 – 26.5 GHz | 1.05:1 | 6 |
| SMC-150051 | WR-51 | 15 – 22 GHz | 1.05:1 | 6 |
| SMC-150062 | WR-62 | 12.4 – 18 GHz | 1.05:1 | 8 |
| SMC-150075 | WR-75 | 10-15 GHz | 1.05:1 | 8 |
| SMC-150090 | WR-90 | 8.2 – 12.4 GHz | 1.05:1 | 8 |
| SMC-150112 | WR-112 | 7.05 – 10 GHz | 1.05:1 | 10 |
| SMC-150137 | WR-137 | 5.85 – 8.2 GHz | 1.05:1 | 12 |
| SMC-150159 | WR-159 | 4.9 – 7.05 GHz | 1.05:1 | 12 |
| SMC-150187 | WR-187 | 3.95 – 5.85 GHz | 1.05:1 | 12 |
| SMC-150229 | WR-229 | 3.3 – 4.9 GHz | 1.05:1 | 14 |
| SMC-150284 | WR-284 | 2.6 – 3.95 GHz | 1.05:1 | 18 |
| SMC-150340 | WR-340 | 2.2 – 3.3 GHz | 1.05:1 | 18 |
| SMC-150430 | WR-430 | 1.7 – 2.6 GHz | 1.05:1 | 18 |
| SMC-150650 | WR-650 | 1.12 – 1.7 GHz | 1.05:1 | 24 |
You can request a quote for this product by filling out this form.
Please contact us for all available specifications and configurations.
